Engle W110 Camshaft 392 Lift 284 Duration 108 Lobe Center
Engle W110 Camshaft 392 Lift 284 Duration 108 Lobe Center
Price:
$153.77
Price:
Sale price
$153.77
Unit price
per
SKUENG-W110
Stock Remaining: 6
Tech Tip
Engle W110 Camshaft with .430 lift and 284 duration. Engle cams are an excellent choice for engine builds whether they are all out race engines, off road stump pullers or street performance cruisers. We recommend you choose your cam based on the engine combination you would like to build and your desired power band location.California Prop 65 Warning:
Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Description
The Engle W110 camshaft is a proven street performance grind designed for mild street mannered air-cooled VW Type 1 engines in the 1600cc - 2276cc range. Increased lift and a little more bump than stock while still being very streetable or daily driver cam. This W110 reacts well to stock 1.1 or 1.25 ratio lifters, single hi-rev springs, and works well with single and dual carburetors.
Specifications
- Advertised duration: ~284°
- Duration @ .050": 247°
- Cam Lift: .392"
- Lobe Center: 108°
- Recommended Rocker Ratio: 1.1:1 (up to 1.25:1 optional)
- Powerband: ~1500–5500 RPM
Fitment
VW Type 1 air-cooled engines (1200cc–1600cc+), including Beetle, Ghia, Bus, and dune buggy builds. Best for stock to mild street stroker engines with single or dual carb setups.
Similar Camshafts
- Engle W100 - Milder, better for stock builds
- Engle W120 - more aggressive, higher RPM power
- Kuhltek K110 Camshaft – Budget alternative to W110
Tech Tips
- Supporting parts: Single or Dual carburetors, header exhaust, HD valve springs, lifters
- Target compression ratio: 8.0:1–8.5:1
- Cam gear bolt torque: 18–25 ft-lbs
- Break-in: Use high-zinc oil, run at 2,000–2,500 RPM for 20 minutes, avoid idling during initial startup
| SKU | ENG-W110 |
| Ships From | Stock |
| Oversized Shipping Required | No |
